Thermal Imaging Specifications

• Sensor Resolution: 256 × 192 pixels (VOx, 12µm pixel pitch)

• Thermal Sensitivity (NETD): ≤ 15 mK

• Objective Lens: 25 mm (F1.0)

• Detection Range: Up to 1,200 meters

• Base Magnification: 4x optical zoom

• Color Palettes: Black hot, white hot, red hot, sky, red, green, and fusion

Day & Night Vision Specifications

• Visible Light Sensor: 3840 × 2160 (4K) CMOS

• Pixel Pitch: 2 µm

• Light Sensitivity: 0.001 lux

• Optical Objective Lens: 50 mm

• Optical Image Stabilization (OIS): Included

• IR Illuminator: Detachable 850nm / 940nm infrared illuminator with a ~350-meter range

Display & Optics

• Displays: Dual 1920 × 1080 OLED displays

• Interpupillary Distance (IPD): 55 – 74 mm adjustment

• Viewing Modes: City, Rain, and Forest scene modes

Rangefinder & Electronics

• Laser Rangefinder (LRF): Integrated 1,000-meter rangefinder

• Functions: Picture-in-Picture (PIP), hot track, electronic compass, gyroscope, photo and video recording

• Storage: External micro SD card supported (up to 128 GB)

• Connectivity: Wi-Fi (PardVision2 app) and USB Type-C

Power & Physical Build

• Battery: Single replaceable 21700 lithium-ion battery (3.7V, up to 4.5 hours runtime)

• External Power: USB Type-C

• Waterproofing: IP67

• Operating Temperature: -30°C to +55°C

• Dimensions: 160 × 146 × 65 mm

• Weight: 809.5 g (without battery)

• Construction Material: Aluminum alloy AL6061 and composite
